Description

Stock #URW382

Bending length                                                           48 in. /1220mm

Capacity mild steel, 1 in flange,

With bending  bar and angle in place                 22ga./0.76mm

Minimum reverse bend (bar and angle removed)   5/16 in./7.95mm

Maximum lift of beam                                               7/8 in/22mm

Finger widths                                                              2, 3 and 4 in./51, 76 and 101mm

Maximum depth of box                                             3 in/76mm

Front to rear adjustment                                          1/4 in./6.35mm

Shipping weight                                                         280lbs./128kg
